High Efficiency COB Track Lighting

Zhenmingshi High Efficiency COB Track Lighting adopt advanced COB technology to achieve high-efficiency lighting and provide excellent lighting effects for various spaces. Zhenmingshi high-efficiency COB track lights are not only novel in style and meet the fashion needs of modern decoration, but also have reliable quality. They are one of Zhenmingshi's latest and best-selling lighting products.

Send Inquiry

Product Description

Zhenmingshi High Efficiency COB Track Lighting can save up to 40% of electricity while maintaining or even improving the lighting effect. Zhenmingshi high-efficiency COB track lights use the latest COB light source with a light efficiency of up to 110lm/w. In addition to the radiator made of aluminum alloy, the other parts of the lamp body are also made of high-quality plastic or metal materials, which have good durability.

Product features:

A variety of beam angles are available: 15°, 24°, 37° and other beam angles are provided. You can choose the appropriate beam angle as needed to achieve key lighting, local lighting or overall lighting effects.

Good color rendering: The High Efficiency COB Track Lighting color rendering index is high, which can truly restore the color of the object, making the color of the illuminated object more vivid and realistic, creating a comfortable and natural lighting atmosphere for the space.

Convenient installation method: The High Efficiency COB Track Lighting adopts a standard rail installation method, which is simple and convenient to install. There is no need for complicated wiring and installation steps. Users can install it by themselves, saving installation costs and time.

Transformer: High-power transformer, realizing the perfect combination of lamps, electrical appliances and light sources.

Optical lens: Equipped with high-efficiency optical-grade lens, low light loss, good illumination, ensuring uniform light distribution

Appearance design: Streamlined design, beautiful, light and simple, easy to install and replace

Core Configuration

Listed company (Philips brand) power supply

Puri chip special customized fresh color

Dimensions

Technical Parameters

Item No.	ZMS-YZLGD-F5036/105
Power	24W/30W/36W/44W/60W
Flux	130-140Lm/W
PF	≥0.95
Input Voltage	220V~245V 50-60Hz
Facade color	Black/White
Material	Cold forged aluminum

LED light	American Bridgechip
Driver	Philips Power Supply
Color	Fresh color/intelligent dimming and color adjustment/3000K/4000K/5000K
CRI	90
Quality	8 years
Cert.of Driven	CCC CE CB ROHS SAA TUV
Light Angle	24°/36°

IES measured indoor lighting photometric data

Light source data		Luminous intensity data Light efficiency: 130.84 lm/W
Model		Peak light intensity (cd)	6852	S/MH(C0/180)	0.63
Nominal power (W)	23.16W	Lamp efficiency (%)	100.0	S/MH (C90/270)	0.65
Rated power supply voltage (V)	220	Total luminous flux (lm)	3030.1	η UP,DN(C0-180)	0.6,46.7
Rated luminous flux(lm)	3030.07	CIE classification	Direct	η UP,DN(C180-360)	0.5,52.2
Number of light sources in the lamp (pcs)	1	Upward luminous flux ratio (8)	1.1	CIBSE SHR NOM	0.50
Measured power supply voltage (V)	220	Downward luminous flux ratio (8)	98.9	CIBSE SHR MAX	0.65
